Engine | Muffler | Air Cleaner (Kasea LM150IIR 2003)
Change Assembly
| # | Product Name | Req'd | Price: | |
|---|---|---|---|---|
| 1 |
Kasea LM150IIR Reverse Assembly
56000-20225-OB
|
|||
| 2 |
Internal Collar
94100-20222-OB
|
|||
| 3 |
Nut Flange Lock M16
9.220.016
|
|||
| 4 |
Bolt, M10X20
9.101.020
|
|||
| 6 |
Bracket, Reverse
8.020.057
|
|||
| 7 |
Lock Nut (M8)
9.200.008
|
|||
| 8 |
Bracket Arm, Reverse
8.020.058
|
$2.09 | ||
| 9 |
Bolt. M8X1.25X40
9.100.840
|
$1.88 | ||
| 10 |
Nut, Flange Lock M10
9.400.010
|
|||
| 11 |
Band, Air Cleaner Connecting Tube
98250-50029-OB
|
|||
| 12 |
Air Cleaner Assy.
6.000.017
|
|||
| 13 |
Carburetor Assy.
16100-KAT-913-1
|
$80.00 | ||
| 14 |
Engine 150Cc
2.000.009
|
|||
| 15 |
Rack Support, Muffler
8.030.005
|
|||
| 16 |
Bolt. M10X25
9.101.025
|
|||
| 17 |
Protector, Muffler
6.000.215
|
|||
| 18 |
Kasea LM150IIR Exhaust Assembly
6.000.015
|
|||
| 19 |
CLAMP
98250-50035-KAT
|
$3.49 | ||
| 20 |
BOOT, SIDE CASE
64000-00035-KAT
|
$19.56 | ||
| 21 |
Nut Flange M6
KS125T-1001008
|
$1.12 |
